Kafka Avro 1

Description

• Running a Kafka cluster locally (Docker)
• Defining the Avro Schema
• Producing Avro messages
• Consuming Avro messages

Prerequisites

• Linux
• JDK 21
• Maven
• Docker

Project Structure

.
├── kafka-docker-compose
│   ├── kafka-ssl
│   │   ├── docker-compose.yml
│   │   ├── README.md
│   │   ├── security
│   │   │   ├── create-certificates.sh
│   │   │   ├── create-jks-certificate.sh
│   │   │   ├── create-pem-certificate.sh
│   │   │   └── remove-certs.sh
│   │   ├── start-cluster.sh
│   │   └── stop-cluster.sh
│   ├── LICENSE
│   ├── README.md
│   ├── single-node-avro-kafka
│   │   └── docker-compose.yml
│   └── single-node-kafka
│       └── docker-compose.yml
├── pom.xml
├── README.md
└── src
    └── main
        ├── java
        │   └── jreact
        │       └── com
        │           └── kafka
        │               └── schema
        │                   └── registry
        │                       ├── consumer
        │                       │   ├── GenericRecordConsumer.java.bak
        │                       │   └── SpecificRecordConsumer.java
        │                       └── producer
        │                           ├── GenericRecordProducer.java.bak
        │                           └── SpecificRecordProducer.java
        └── resources
            ├── avro
            │   └── SimpleMessage.avsc
            └── log4j.properties

Running Docker

Got to folder single-node-avro-kafka and and start:

docker-compose up -d

docker ps

Output:

 CONTAINER ID   IMAGE                                   COMMAND                  CREATED       STATUS       PORTS                                        NAMES
 2949b466be6c   confluentinc/cp-schema-registry:7.5.2   "/etc/confluent/dock…"   6 hours ago   Up 6 hours   0.0.0.0:8081->8081/tcp                       sn-schema-registry
 981051ab7fed   confluentinc/cp-kafka:7.5.2             "/etc/confluent/dock…"   6 hours ago   Up 6 hours   0.0.0.0:9092->9092/tcp                       sn-kafka
 f07a02a7f3d4   confluentinc/cp-zookeeper:7.5.2         "/etc/confluent/dock…"   6 hours ago   Up 6 hours   2888/tcp, 0.0.0.0:2181->2181/tcp, 3888/tcp   sn-zookeeper

docker exec -it sn-kafka /bin/bash

cd /opt

kafka-topics --list --bootstrap-server localhost:9092

Result:

__consumer_offsets
_schemas
avro-topic

avro-topic is created by public class SpecificRecordProducer

Defining the Avro Schema

SimpleMessage.avsc

{
	"type": "record",
	"name": "SimpleMessage",
	"namespace": "com.jreact.kafka.schema.registry.avro",
	"fields": [
		{"name": "content", "type":"string", "doc": "Message content"},
		{"name": "date_time", "type":"string", "doc": "Datetime when the message was generated"}
	]
}

Running avro-maven-plugin

mvn clean package

Result

├── src
│   └── main
│       ├── java
│       │   └── com
│       │       └── jreact
│       │           └── kafka
│       │               └── schema
│       │                   └── registry
│       │                       ├── avro
│       │                       │   └── SimpleMessage.java

SpecificRecordProducer.java

package com.jreact.kafka.schema.registry.producer;

import com.jreact.kafka.schema.registry.avro.SimpleMessage;
import io.confluent.kafka.serializers.KafkaAvroSerializer;
import io.confluent.kafka.serializers.KafkaAvroSerializerConfig;
import org.apache.avro.specific.SpecificRecord;
import org.apache.kafka.clients.producer.KafkaProducer;
import org.apache.kafka.clients.producer.Producer;
import org.apache.kafka.clients.producer.ProducerConfig;
import org.apache.kafka.clients.producer.ProducerRecord;
import org.apache.kafka.common.serialization.StringSerializer;

import java.time.Instant;
import java.util.Properties;

public class SpecificRecordProducer {

    public static void main(String[] args) {
        SpecificRecordProducer specificRecordProducer = new SpecificRecordProducer();
        specificRecordProducer.writeMessage();
    }

    public void writeMessage() {
        Properties properties = new Properties();
        properties.put(ProducerConfig.BOOTSTRAP_SERVERS_CONFIG, "localhost:9092");
        properties.put(ProducerConfig.KEY_SERIALIZER_CLASS_CONFIG, StringSerializer.class);
        properties.put(ProducerConfig.VALUE_SERIALIZER_CLASS_CONFIG, KafkaAvroSerializer.class);
        properties.put(KafkaAvroSerializerConfig.SCHEMA_REGISTRY_URL_CONFIG, "http://localhost:8081");

        Producer<String, SpecificRecord> producer = new KafkaProducer<>(properties);

        //create the specific record
        SimpleMessage simpleMessage = new SimpleMessage();
        simpleMessage.setContent("Hello world");
        simpleMessage.setDateTime(Instant.now().toString());

        // creates avro-topic if it doesn't exist
        // public ProducerRecord(String topic, Integer partition, Long timestamp, K key, V value, Iterable<Header> headers) {
        //    ...
        // }
        ProducerRecord<String, SpecificRecord> record = new ProducerRecord<>("avro-topic", null, simpleMessage);

        producer.send(record);
        //ensures record is sent before closing the producer
        producer.flush();

        producer.close();
    }
}

SpecificRecordConsumer.java

package com.jreact.kafka.schema.registry.consumer;

import com.jreact.kafka.schema.registry.avro.SimpleMessage;
import io.confluent.kafka.serializers.KafkaAvroDeserializer;
import io.confluent.kafka.serializers.KafkaAvroDeserializerConfig;
import org.apache.kafka.clients.consumer.ConsumerConfig;
import org.apache.kafka.clients.consumer.ConsumerRecord;
import org.apache.kafka.clients.consumer.ConsumerRecords;
import org.apache.kafka.clients.consumer.KafkaConsumer;
import org.apache.kafka.clients.producer.ProducerConfig;
import org.apache.kafka.common.serialization.StringDeserializer;

import java.time.Duration;
import java.util.Collections;
import java.util.Properties;

public class SpecificRecordConsumer {

    public static void main(String[] args) {
        SpecificRecordConsumer genericRecordConsumer = new SpecificRecordConsumer();
        genericRecordConsumer.readMessages();
    }

    public void readMessages() {
        //create kafka producer
        Properties properties = new Properties();
        properties.put(ProducerConfig.BOOTSTRAP_SERVERS_CONFIG, "localhost:9092");
        properties.put(ConsumerConfig.GROUP_ID_CONFIG, "specific-record-consumer-group");
        properties.put(ConsumerConfig.AUTO_OFFSET_RESET_CONFIG, "earliest");
        properties.put(ConsumerConfig.ENABLE_AUTO_COMMIT_CONFIG, false);

        properties.put(ConsumerConfig.KEY_DESERIALIZER_CLASS_CONFIG, StringDeserializer.class);
        properties.put(ConsumerConfig.VALUE_DESERIALIZER_CLASS_CONFIG, KafkaAvroDeserializer.class);

        properties.put(KafkaAvroDeserializerConfig.SCHEMA_REGISTRY_URL_CONFIG, "http://localhost:8081");
        properties.put(KafkaAvroDeserializerConfig.SPECIFIC_AVRO_READER_CONFIG, true);

        KafkaConsumer<String, SimpleMessage> consumer = new KafkaConsumer<>(properties);

        consumer.subscribe(Collections.singleton("avro-topic"));

        //poll the record from the topic
        while (true) {
            ConsumerRecords<String, SimpleMessage> records = consumer.poll(Duration.ofMillis(100));

            for (ConsumerRecord<String, SimpleMessage> record : records) {
                System.out.println("Message content: " + record.value().getContent());
                System.out.println("Message time: " + record.value().getDateTime());
            }
            consumer.commitAsync();
        }

    }
}

---

Source Code:
https://github.com/ZbCiok/zjc-examples/tree/main/reactive-messaging/kafka/kafka-avro-1

Based on:
https://codingharbour.com/apache-kafka/guide-to-apache-avro-and-kafka/
